Scenario: You need a new staging VM to test out some Group Policy settings for a domain that resides on a different VLAN than the host that will store your staging VM. For example, let’s say that you wanted to run this VM using VirtualBox on your local machine. Your machine is on the I.T. Department VLAN (5), but the target domain resides on VLAN 3.
Your machine is running Ubuntu — any recent version (I used 15.10 for this post) will work for this example. The 10,000ft view of what needs to be done is as follows:
- Ensure that the switchport that your workstation is connected to is a member of both VLANs. In my scenario, I have the following settings:
switchport trunk native vlan 5 switchport trunk allowed vlan 3
- Install the vlan package on your machine
- Configure a virtual interface with the appropriate VLAN info
- Configure your VM to use that interface exclusively
This post assumes you already have the VM up and running — in this example we’re using VirtualBox but pretty much any virtualization software should work. Go ahead and install the vlan package:
you@localhost:~$ sudo apt-get install vlan you@localhost:~$ sudo modprobe 8021q you@localhost:~$ sudo echo "8021q" >> /etc/modules
Add the virtual interface(s). On my machine, I have one interface named enp9s0; yours will probably be different. Adjust as necessary.
you@localhost:~$ sudo vi /etc/network/interfaces
Add your configuration. Mine is as follows:
auto lo iface lo inet loopback auto enp9s0 iface enp9s0 inet dhcp ## Target hosts/domain VLAN ## FYI: IPv4 addressing scheme is 10.0.3.0/24 auto vlan3 iface vlan3 inet dhcp vlan-raw-device enp9s0 ## Example VLAN w/ static IP assignment auto vlan99 iface vlan99 static address 10.10.10.10 netmask 255.255.255.0 gateway 10.10.10.1
See The basic syntax of “/etc/network/interfaces” for more information on the available configuration options for /etc/network/interfaces
I did run into some trouble during this configuration, mainly because there are some conflicting instructions on the net. You do not have to use vconfig to create the interface before adding it to /etc/network/interfaces … you can if you like, but it isn’t necessary. During this process, if you run into issues with interfaces not being brought up, you should take a look in /sys/class/net to see which interfaces have actually been created:
you@localhost:~$ ls /sys/class/net enp9s0 lo vlan3 vlan99
To remove any of your virtual interfaces, simply run the following command (where ‘vlan99’ is the interface you wish to remove):
you@localhost:~$ sudo vconfig rem vlan99 Removed VLAN -:vlan99:-
Now that you have your VLAN interface configured on your local host, we need to tell your VM to use it. This is trivial — in VirtualBox, navigate to the network settings of the VM and make sure that:
- “Bridged Adapter” is selected in the “Attached to:” dropdown box
- Select the appropriate adapter in the “Name:” dropdown box
Note: the VM can either be running or not … it makes no difference):
Then check your network settings in the VM (assuming DHCP — if not you’ll have to reconfigure them manually):
If all goes well, you should now have a VM that will act behave like any of the workstations on the other VLAN with regards to networking.
